AGX
CONSTRUCTION
Dual safety construction
? Dual restoration spring
? Double cut-off type
2mm min.
4mm or more contact gap
(2mm or more on one side) × 2
.250 Quick-connect terminal
DIMENSIONS
1 Form A
CAD Data
The CAD data of the products with a
32
CAD Data
mark can be downloaded from: http://industrial.panasonic.com/ac/e
mm General tolerance: ± 0.4
Hole cutting dimension
R0.3 max.
17
?
15 + 0.1
5 dia.
( F.P. ) ( O.P. )
2.3
A
2 Form A
24.6 22.5
14
Panel thickness
Dimension A
1.0 to 1.75
?
30.2 + 0.1
1.75 to 2.5
?
30.5 + 0.1
CAD Data
.250 Quick-connect terminal
3.6
15
10.6
6.35
8.75
3
(Copper is standard as panel material)
27
14.6
Remark: 1 Form A type does not have terminal No.1
nor No.2
3 Form A
CAD Data
32
8 dia.
29.8
Hole cutting dimension
R0.3 max.
?
27.8 + 0.1
A
Power switching contact
( F.P. ) ( O.P. )
2.3
Panel thickness
Dimension A
0.8 to 1.75
?
30.2 + 0.1
1.75 to 2.5
?
30.5 + 0.1
24.6 22.5
14
10.6
0.65
(Copper is standard as panel material)
? Signal switching contact
.250 Quick-connect terminal
3.6
6.35
2.2
2.2
15
11.3
10
7.1
10.6
Signal switching contact
27
27.2
2.8
3.6
15
27
Remark: Power switching contact type has .250
Quick-connect terminal and signal switching contact
type has .110 Quick-connect terminal.
AECTB19E 201201-T
Panasonic Corporation
Automation Controls Business Unit
industrial.panasonic.com/ac/e
